Hierarchy of Administration Servers with a secondary Administration Server in DMZ
The schema shows a hierarchy of Administration Servers in which the secondary Administration Server located in DMZ receives a connection from the primary Administration Server (see the table below for schema clarifications). When combining two Administration Servers into a hierarchy, make sure that port 13291 is accessible on both Administration Servers. Administration Console connects to the Administration Server through port 13291.
Subsequently, when the Administration Servers are combined into a hierarchy, you will be able to administer both of them by using Administration Console connected to the primary Administration Server. Therefore, the accessibility of port 13291 of the primary Administration Server is the only prerequisite.
Hierarchy of Administration Servers with a secondary Administration Server in DMZ (traffic)
Device |
Port number |
Name of the process that opens the port |
Protocol |
TLS |
Port purpose |
---|---|---|---|---|---|
Secondary Administration Server |
13000 |
klserver |
TCP |
Yes |
Receiving connections from the primary Administration Server |
